Brass push in fitting for matric and inch size tube NPT connection Thread

Brass push in fitting for matric and inch size tube NPT connection Thread Specification

Thickness
Standard wall thickness as per tube size (metric and inch), typically 1.0-2.5 mm

Surface Treatment
Nickel plated / Natural brass finish

Machining Method
Precision CNC machining

Max Tolerance
0.05 mm

Weight (kg)
0.015 0.120 (depending on model)

Connection Mode
Push-in tube connection

Thread Size Range
1/8" NPT to 1/2" NPT

Release Ring Material
Polymer or brass

Thread Type
NPT (National Pipe Taper)

Material
High-quality forged brass

Mounting
Threaded directly into NPT port

Sealing
Pre-assembled O-ring for leak-free connection

Working Temperature
-20°C to +80°C

Corrosion Resistance
High

Working Pressure
up to 1.6 MPa (232 psi)

Reusable
Yes, suitable for multiple installations/removals

Tube Size Compatibility
Metric (4 mm to 16 mm) and Inch (1/8" to 1/2") tubes

Application
Pneumatic and fluid systems

About Brass push in fitting for matric and inch size tube NPT connection Thread

Our Brass Push-In Fitting receives favorable reviews for its potent performance and rarefied reliability in pneumatic and fluid systems. Manufactured from high-quality forged brass, this fitting features precision CNC machining and a nickel plated or natural brass finish for high corrosion resistance. Designed for both metric (4 mm to 16 mm) and inch (1/8" to 1/2") tubes, it supports NPT thread sizes from 1/8" to 1/2". Take advantage of this noteworthy bargain-enjoy a leak-free, reusable solution with a pre-assembled O-ring, suitable for multiple installations in demanding environments.

Versatility and Special Features for a Range of Users

The Brass Push-In Fitting caters to both metric and inch tube systems, making it suitable for diverse industrial and commercial uses. Its robust design incorporates a pre-assembled O-ring for leak-free operation and can be reused multiple times, saving on replacement costs. Frequently used by professionals in pneumatic and fluid handling sectors, its nickel or natural brass finish ensures durability and corrosion resistance, while easy push-in and threaded connections streamline installation.

Certifications, FOB Port, and Sample Acquisition Process

Our brass fittings are certified to meet industry standards, ensuring consistent quality upon every purchase order. Goods transport is usually arranged from major Indian FOB ports, offering flexible logistics for bulk orders. For a tailored experience, sample policies are customer-centric-simply submit your inquiry with the asking price, and our team will guide you through the acquisition process. We prioritize transparent transactions and product satisfaction from order placement to delivery.

FAQ's of Brass push in fitting for matric and inch size tube NPT connection Thread:

Q: How do I select the right Brass Push-In Fitting size for my application?

A: Determine your tube's outer diameter and required NPT port size. This fitting accommodates metric tubes (4 mm to 16 mm) and inch tubes (1/8" to 1/2"). Match these measurements to the available fitting sizes for proper installation.

Q: What makes this brass fitting noteworthy for pneumatic and fluid systems?

A: Its high-quality forged brass construction, pre-assembled O-ring, and outstanding corrosion resistance make it both potent and long-lasting. The push-in connection simplifies installation, while its reusability allows for multiple setups in demanding environments.

Q: Where are the Brass Push-In Fittings typically used?

A: These fittings are widely used in pneumatic and fluid handling systems across manufacturing, automotive, and processing industries, particularly where robust, leak-free connections are essential.

Q: What is the process for purchasing and requesting samples?

A: Submit a purchase order or inquiry including your desired asking price and product specifications. Sample policies are customer-focused, and samples can be arranged upon request. Goods transport arrangements are made from major Indian FOB ports for your convenience.

Q: How does the pre-assembled O-ring benefit the installation?

A: The pre-assembled O-ring ensures a leak-free connection right from installation, eliminating the need for additional sealing and reducing assembly time and maintenance concerns.
